Inflatable Air Bladder

Classification of inflatable shaft airbags
Inflatable shaft airbag inflatable sleeve is generally key or plate type. That is, the sleeve convex portion is a single key or a whole sheet. It is placed outside the three-inch inflatable shaft. Suitable for items with a large inner diameter of the paper tube. For example: paper machine, textile machine, etc. Its working principle is similar to the inflation axis.

Inflatable shaft airbag plate type air expansion shaft:
Also known as plate type air expansion shaft, slat type air expansion shaft, tile type air expansion shaft, etc., but the working principle is the same. Features: The expansion part is a plate, usually the height of the expansion can reach 4mm to 5mm, such as the diameter before expansion is 74mm to 75mm, the diameter after expansion can reach 78mm to 79m, special expansion height, separately required.

3-inch plate type air expansion shaft, usually using the inner diameter of the coil tube is 76mm. The plate type air expansion shaft expands from the whole plate, the fulcrum is evenly distributed, and the force is uniform. It can be used for mechanical or winding with higher precision. Light items, such as: electronic materials \ battery materials \ foam cotton \ plush \ paper towels \ non-woven \, etc., mainly based on actual needs.

Inflatable shaft airbag key type air expansion shaft: also known as convex key type air expansion shaft, key strip type air expansion shaft, and so on, but the working principle is the same. Features: The expansion part is a key strip. Generally, the unilateral expansion height can reach 5mm to 6mm. For example, the diameter before expansion is 74mm to 75mm, and the diameter after expansion can reach 79mm to 82mm. The special expansion height is separately required.

3 inch key type air expansion shaft, usually using paper tube inner diameter is 76mm. The key type air expansion shaft expands from a single key bar, the fulcrum spreads to each key bar, balances the force, and can be applied to the mechanical winding capacity. Items, such as: cloth \ paper products \ film \ print \ leather \ composite materials, etc., mainly determined according to actual needs.
