Photoelectric Guide Sensor Instructions For Using

The photoelectric guide sensor is a sensor that uses a photoelectric element as a detection element. It first converts the measured change into a change in the optical signal, and then further converts the optical signal into an electrical signal by means of the optoelectronic component. The detection distance is long. By detecting a detection distance of 10 m or more in the pair of shots, other detection means can be realized. The response time is short.

The light itself is high speed, and the sensor's circuitry is made up of electronic components, so it does not include mechanical working hours. Non-contact detection is possible. It is possible to perform inspection without mechanical contact with the inspection object, so there is no damage to the detection object and the sensor. Therefore, the sensor can be used for a long time.

The type of the photoelectric guide sensor is determined according to the measurement object and the measurement environment. To carry out a specific measurement work, we must first consider the principle of the sensor, which needs to be analyzed after analyzing various factors. Because even if it is measuring the same physical quantity, there are many kinds of sensors available for selection. Which kind of sensor is more suitable, you need to consider the following specific problems according to the characteristics to be measured and the conditions of use of the sensor:

The size of the range; the position of the measured position on the sensor volume; the measurement method is contact or non-contact; the signal extraction method, wired or non-contact measurement; the source of the sensor, domestic or imported, the price can withstand, or self-developed .

Modern photoelectric guide sensors vary widely in principle and structure. How to select sensors according to specific measurement purposes, measurement objects and measurement environment is the first problem to be solved when performing a certain amount of measurement. When the sensor is determined, the matching measurement method and measuring device can be determined. The success or failure of the measurement results depends to a large extent on whether the sensor selection is reasonable.
